Amphenol Amphenol High Speed Hermetic
Aerospace Connectors

38999
III Amphenol Aerospace is offering superior electrical
HD performance plus the rugged design of a glass
Dualok sealed hermetic connector.
II
I CuSTOM HErMETIC
SJT CONNECTOrS:
Accessories Amphenol glass sealed hermetic connectors
are available in a wide variety of Mil-Spec
Aquacon
and custom configurations.
Herm/Seal
PCB
FEATurES ANd BENEFITS:
HIgH • Leakage rate of 1 x 10-7 cc of He/sec or less
SPeeD • Fused glass insert in steel shell
• Options include:
Fiber • Special flanges
Optics • PC board mounting stand-offs
Contacts • PC board mounting tails
Connectors • EMI Filtering
Cables • Through bulkhead configurations
• Crimp termination
eMI Filter Transient

High Speed Hermetic Connectors have been designed to meet the
demands of today’s harsh environments and superior electrical needs CONNECTOr FEATurES:
Incorporates size 8 coax contacts
26482 Matrix 2 CONNECTOr SpECIFICATIONS & BENEFITS: • Termination choices:
• Printed circuit tails
• Leak rate of 1X10-7 cc He/sec or less • Solder cup
• Shell Finishes:
@ 1atm differential
83723 III Matrix|Pyle • Fused glass insert in stainless steel • Passivated stainless steel, 200°C
• Passivated stainless steel with Nickel plate
• Operating Frequency: 0-500 MHz
• Leak rate of 1X10-7 cc He/sec or less
• Insulation Resistance: 1,000 megohms min. at 25°C
• Dielectric Withstanding Voltage: @ 1atm differential
Center to Outer 500 VAC Rms at sea level
26500 Pyle • Contact Resistance: CONNECTOr OpTIONS:Or O
CONNECT
• Center at 1 Amp, 55 millivolts max. voltage drop
at 25°C
•
• Outer at 1 Amp, 55 millivolts max. voltage drop • Special flangesSpecial flanges
• PC board mounting stand-offs
• PC board mounting stand-offs
at 25°C
• EMI filtering
5015 Crimp Rear Release Matrix • EMI filtering
• Through-bulkhead configurations
• Through-bulkhead configurations
22992 Class L EpOxy SEALEd CONNECTOrS
Amphenol epoxy sealed connectors are a light-weight alternative to glass sealed hermetic connectors for use in avionics and
other weight-sensitive applications where a high level of sealing is required. Epoxy sealed connectors are an optimal solution
Back- Shells when increasingly stringent sealing requirements must be met in radio and vetronics applications.

• Same epoxy as used in EMI filter connectors
• Less than 1 x 10-5 cc of He/sec leak rate
Options Others • Maintained after temperature cycling, 5 cycles -55 to +125°C
• Custom designs available with lower leak rates upon request
• Available in standard and custom configurations including PC tail, solder cup, and
crimp termination, board mounting stand-offs, and thru-bulkhead configurations.

For other epoxy sealed connector options please see “Filter How to Order” page 278 or contact Amphenol Aerospace

140 Contact Amphenol Aerospace for more information at 800-678-0141 or Filterapps@amphenol-aao.com • www.amphenol-aerospace.com
