Page 147 - Amphenol_Circular_12_C

Amphenol Circular Connectors – PCB Contacts
Aerospace Insert Availability

38999 The following table lists the most commonly used insert arrangements for printed circuit board application of
MIL-DTL-38999 circular connectors. This represents the most readily avail able patterns within these series.
III See illustrations of these selected patterns on the following pages. If you require other arrangements than
HD what are shown here, consult Amphenol for further availability.
Dualok Example: Shell Size is the first number (8–3) Insert Arrangement is second number.
II MIL-DTL-38999 Contact Size*
I
SJT JT LJT Tri-Start
MIL-DTL-38999 MIL-DTL-38999 MIL-DTL-38999 Service Total
Accessories Series II Series I Series III Rating Contacts 22D 20 16
Aquacon 8-3 9-3 M/I 3 3
Herm/Seal 8-35 9-35 9-35 M 6 6
PCB
8-98 9-98 9-98 I 3 3
10-5 11-5 11-5 I 5 5
HigH
Speed 11-6 I 6 6
Fiber 10-35 11-35 11-35 M 13 13
Optics 12-3 13-3 II 3 3
Contacts 12-35 13-35 13-35 M 22 22
Connectors
Cables 14-18 15-18 15-18 I 18 18
14-19 15-19 15-19 I 19 19
eMi Filter Transient 14-35 15-35 15-35 M 37 37 26
26
16-26
I
17-26
17-26
16-35
18-11 17-35 17-35 M 55 55 11
II
19-11
11
19-11
26482 Matrix 2 18-32 19-32 19-32 M 32 66 32
I
19-35
18-35
19-35
66
20-27 21-27 I 27 27
83723 iii Matrix|pyle 20-35 21-35 21-35 M 79 79 41
21-41
21-41
41
20-41
I
22-35 23-35 23-35 M 100 100
26500 pyle 22-55 23-55 23-55 I I 55 55 31
31
24-31
24-35 25-35 25-35 M 128 128
24-61 25-61 25-61 I 61 61
5015 Crimp Rear Release Matrix * For information on size 12 PC tail contacts consult Amphenol Aerospace.
Printed Circuit Boards are available in other series like MIL-DTL-26482 and
MIL-5015 Connectors. Please contact Amphenol Aerospace for more information.
22992 Class L
Back- Shells MIL-DTL-26482 MIL-5015 Connector

• Medium size, widely used circular • Medium–heavy weight, time-tested circular
• Operating voltage to 1,000 VAC (RMS) at sea level
Options Others • Series 1 (PT) - Bayonet coupling - most commonly • Operating voltage to 1,500 VAC (RMS) at sea level
• Environmentally resistant or general duty
used in PCB applications
• Environmentally resistant • Threaded coupling
• Solder or crimp rear insertion contacts in mating plug
• Solder or crimp front and rear release contacts in
mating plug Black/green zinc alloy plating (cadmium-free) available
Black/green zinc alloy plating (cadmium-free) available

146 Contact Amphenol Aerospace for more information at 800-678-0141 • www.amphenol-aerospace.com
