Page 115 - Amphenol_Circular_12_C

Amphenol MIL-DTL-38999, Series II JT
Aerospace MIL-DTL-38999, Series I LJT

Strain Relief (Crimp Type)
38999
III Series II JT Series I LJT
HD
Dualok
II
I
SJT L
Accessories
B
Aquacon
Herm/Seal G
BB
PCB
Y
HIgH
SPeeD GROMMET
Fiber
Optics
* 10-405982-XXX (MS27506XXX-2 reference M85049/49)
Contacts
Connectors
Cables For MS stamping identification, accessories must be ordered by
MS part number.
If ordered by 10-part number, they will be stamped with said number.
eMI Filter Transient *To complete order number, add shell size and suffix number.

10-Number
Finish
Suffix
Suffix
Suffix MS27506 M85049/49
Chromate Treat
-XX0
NA
26482 Matrix 2 Anodic Coating -XX5 CXX-2 (-2-XXA)
-XX7
Cadmium Plate Nickel Base
NA
AXX-2
-XX9
83723 III Matrix|Pyle Olive drab, Cadmium, Nickel base -XXG BXX-2 (-2-XXW)
(-2-XXN)
FXX-2
Electroless Nickel
For example: Shell size 10 with cadmium plate, nickel base would be
10-405982-107 or M85049/49-2-10W
26500 Pyle Shell B Dia. Y Thread (Modified) BB Dia. Screw
Size +.010 G Max. L Max. Size Class 2B Modified Minor Dia. +.000 Size
–.025 .775 .984 .4375-28UNEF .399 – .405 –.011 6-32UNC
8
.125
.250
5015 Crimp Rear Release Matrix 10 .188 .837 .984 .5625-24UNEF .524 – .529 .312 6-32UNC
12
.312
.649 – .654
.6875-24UNEF
.963
.984
.438
6-32UNC
14 .375 1.087 1.234 .8125-20UNEF .766 – .771 .562 6-32UNC
22992 Class L 16 .500 1.150 1.234 .9375-20UNEF .891 – .896 .625 6-32UNC
8-32UNC
.750
1.002 – 1.007
1.234
1.400
.625
1.0625-18UNEF
18
20 .625 1.400 1.234 1.1875-18UNEF 1.135 – 1.140 .750 8-32UNC
22 .750 1.587 1.359 1.3125-18UNEF 1.252 – 1.257 .938 8-32UNC
Back- Shells 24 .800 1.681 1.281 1.4375-18UNEF 1.377 – 1.382 1.000 8-32UNC
All dimensions for reference only.
Note: For solder type cable clamp 10-241055-XXX (M85049/49) consult Amphenol Aerospace.
Options Others
114 Contact Amphenol Aerospace for more information at 800-678-0141 • www.amphenol-aerospace.com
