How to Order
Circular Connector Backshells How to Order

There is no single shield termination technology or
Cable Sealing Backshell Designs methodology that will meet every customer require-

Submersible Backshells ment. For this reason, Glenair supports every popu-
lar shield termination method with the full range of
shell sizes, materials, platings and tooling, including:
• Single and Multiple Conical Rings
• Crimp Rings
• Banding Terminations
• Castellated or Splined Rings
• Lampbase Thread Rings
This Cable Sealing Backshell offers immersion
protection to 6 ft. when used with impervious jack- • Radial Compression Springs
eted cables. A resilient grommet which fits into a • Integrated Shield Socks
counterbore in the backshell compresses and seals • Magnaforming
against the cable jacket when the threaded strain
™
relief is tightened. This backshell is described as • Tinel Lock-Rings
"submersible" throughout this catalog. Customer selection depends on many factors,
Water-Tight Backshells including cost, repairability, shield type and construc-
tion, cable diameter and type, cable jacket thick-
ness, weight, shock and vibration, strain-relief, cor-
rosion resistance and so on. The primary factor is
cable construction: what type of shield is being ter-
minated, where the shield or combination of shields
is located within the cable or wire bundle, and how
difficult the outer jacket is to work with. Customer
preference, established methods and practices, tra-
This Cable Sealing Backshell provides a resil- dition, manual skill levels and inspection procedures
ient grommet as an integral part of the cable strain must also be considered.
relief; it is described as "water-tight" throughout
this catalog and prevents water incursion up to 3 ft. The relative effectiveness of each style can be
measured using a transfer impedance test. The
Splash-Proof Backshells transfer impedance test is the most widely accepted
absolute measure of a shield's performance. It is
used to evaluate cable shield performance against
electrostatic discharge and radiated emissions cou-
pling at frequency ranges up to 1 GHz. This testing
method is recommended by the International
Electrotechnical Commission as well as the military.
Test reports for most standard termination technolo-
gies are available upon request from the factory.
For applications requiring only moisture resis-
tance and sealing against dust, Glenair offers these Corrosion Protection in Electromagnetic
Environmental Resisting Backshells. An effective Interconnect Systems
sealing barrier is created by a resilient grommet at Glenair has a responsibility to deliver intercon-
the backshell cable entry. This backshell design is nect systems and hardware to its customers with-
described as "splash-proof" in this catalog out "built-in" corrosion problems. As part of this ef-
fort we have pioneered the use of composite ther-
