370-001
                                                   Submersible  Cable  Sealing  Backshell
                                                                  with Strain Relief
       37
                                                          Low Profile - Rotatable Coupling

                                                          370 F S 001 M 16 10 M 6

                CONNECTOR                  Product Series                          Length: S only
                                                                                     (1/2 inch increments:
               DESIGNATORS                 Connector                                 e.g. 6 = 3 inches)
               A-F-H-L-S                   Designator                              Strain Relief Style


                 ROTATABLE                 Angle and Profile                         (H, A, M, D)
                                             A = 90°
                  COUPLING                   B = 45°                               Cable Entry (Tables X, XI)
                                             S = Straight
                                                                                   Shell Size (Table I)
                                           Basic Part No.
                       Length ± .060 (1.52)                                        Finish (Table II)
                  Minimum Order Length 2.0 Inch
                          (See Note 5)        A Thread                                 Length ± .060 (1.52)
                                              (Table I)           O-Ring          Minimum Order Length 1.5 Inch
                                                                                          (See Note 5)
                              O-Ring
                                                   C Typ.
                                                  (Table I)                                 G
                                                                                         (Table III)
                STYLE 2
               (STRAIGHT                                   E
               See Note 1)                               (Table III)
                          .88 (22.4)
                            Max                                         F (Table III)                    H
                               O-Ring                                                                 (Table III)


                                          Now Available
                                          with the “NESTOR”
                                Glenair’s Non-Detent,
                 STYLE 2        Spring-Loaded, Self-
                (45° & 90°      Locking Coupling.
               See Note 1)      Add “-445” to Specify
                                This AS85049 Style “N”
                                Coupling Interface.

                 STYLE H                  STYLE A                     STYLE M                  STYLE D
                Heavy Duty              Medium Duty                  Medium Duty             Medium Duty
                  (Table X)               (Table XI)                   (Table XI)              (Table XI)
                    T                           W                      X                            .135 (3.4)
                                                                                                      Max


                          Cable  V               Cable  Y                    Cable  Y               Cable  Z
                         Range                  Range                        Range                  Entry
