Page 208 - Circular Connector Backshells and Accessories

380-013
EMI/RFI Non-Environmental Backshell
with Strain Relief
38
Type D - Rotatable Coupling - Standard Profile

380 F H 013 M 24 12 A
CONNECTOR
DESIGNATORS Product Series Strain Relief Style (H, A, M, D)
A-F-H-L-S Connector Cable Entry (Table X, XI)

Designator
ROTATABLE Shell Size (Table I)
COUPLING Angle and Profile
H = 45° Finish (Table II)
J = 90°
TYPE D INDIVIDUAL See page 38-70 for straight Basic Part No.
OR OVERALL
SHIELD TERMINATION

A Thread
E G
(Table I) (Table III) (Table III)

F (Table III)
C Typ.
(Table I)

H
(Table III)
.88 (22.4) Max

Now Available
with the “NESTOR”
Glenair’s Non-Detent,
Spring-Loaded, Self-
STYLE 2 Locking Coupling.
(See Note 1)
Add “-445” to Specify
This AS85049 Style “N”
Coupling Interface.

STYLE H STYLE A STYLE M STYLE D
Heavy Duty Medium Duty Medium Duty Medium Duty
(Table X) (Table XI) (Table XI) (Table XI)
T W X .135 (3.4)
Max

Cable Cable Y Cable Cable
Range V Range Range Y Entry Z
