Page 215 - Circular Connector Backshells and Accessories

380-014
EMI/RFI Non-Environmental Backshell
with Strain Relief 38
Type D - Direct Coupling - Split Shell

See inside back cover fold-out or pages 13 and 14 for unabridged Tables I and II.
TABLE III: FRONT ADAPTER
J Max - Conn. Designator
Shell A-E-F TABLE IV: ELBOW DIMENSIONS
Size J-H-L-S D-B-G-K C Elbow E F G H
08/09 1.180 (30.0) 1.440 (36.6) Size Max Max Max Max
10/11 1.180 (30.0) 1.440 (36.6) 03 .440 (11.2) 1.730 (43.9) .680 (17.3) 1.670 (42.4)
1.785 (45.3)
04
1.725 (43.8)
.500 (12.7)
.750 (19.1)
12/13 1.180 (30.0) 1.440 (36.6) 1.735 (44.1) 06 .560 (14.2) 1.855 (47.1) .810 (20.6) 1.795 (45.6)
14/15 1.180 (30.0) 1.440 (36.6) 1.915 (48.6)
16/17 1.380 (35.0) 1.560 (39.6) 1.915 (48.6) 08 .620 (15.7) 1.887 (47.9) .870 (22.1) 1.827 (46.4)
1.987 (50.5)
.680 (17.3)
1.927 (48.9)
.930 (23.6)
10
18/19 1.380 (35.0) 1.560 (39.6) 1.915 (48.6)
20/21 1.380 (35.0) 1.560 (39.6) 1.915 (48.6) 12 .750 (19.1) 2.045 (51.9) 1.000 (25.4) 1.985 (50.4)
16
2.046 (52.0)
2.106 (53.5) 1.060 (26.9)
.820 (20.8)
22/23 1.380 (35.0) 1.560 (39.6) 1.915 (48.6) 20 .940 (23.9) 2.225 (56.5) 1.180 (30.0) 2.165 (55.0)
24/25 1.380 (35.0) 1.560 (39.6) 1.915 (48.6)
28/29 1.610 (40.9) 1.560 (39.6) 1.915 (48.6) 24 1.300 (33.0) 2.386 (60.6) 1.300 (33.0) 2.326 (59.1)
32/33 1.610 (40.9) 1.750 (44.5) 1.915 (48.6)
36 1.610 (40.9) 1.750 (44.5) 1.915 (48.6) TABLE II: STANDARD FINISHES
40 1.610 (40.9) 2.190 (55.6) 1.915 (48.6) GLENAIR
SYMBOL FINISH
TABLE X: CABLE ENTRY B Cadmium Plate, Olive Drab
Dash T V Cable Range M Electroless Nickel
No. Max Max Min Max NF Cadmium Plate, Olive Drab
Over Electroless Nickel
04 .780 (19.8) .957 (24.3) .125 (3.2) .312 (7.9) See Inside Back Cover
06 .780 (19.8) 1.145 (29.1) .250 (6.4) .437 (11.1) for Additional Finish Options
08 .780 (19.8) 1.332 (33.8) .312 (7.9) .562 (14.3)
10 .780 (19.8) 1.332 (33.8) .350 (8.9) .625 (15.9) 1. Metric dimensions (mm) are indicated in
12 .811 (20.6) 1.551 (39.4) .500 (12.7) .750 (19.1) parentheses.
16 .905 (23.0) 1.770 (45.0) .625 (15.9) .937 (23.8) 2. Cable range is defined as the accommo-
20 1.092 (27.7) 2.113 (53.7) .875 (22.2) 1.250 (31.8) dations range for the wire bundle or cable.
24 1.124 (28.5) 2.363 (60.0) 1.000 (25.4) 1.375 (34.9) Dimensions shown are not intended for
28 1.399 (35.5) 2.770 (70.4) 1.250 (31.8) 1.625 (41.3) inspection criteria.
32 1.399 (35.5) 3.020 (76.7) 1.437 (36.5) 1.875 (47.6) 3. When using Connector Designator B refer
to pages 18 and 19 for part number
development.
TABLE XI: CABLE ENTRY
Dash W X Y Z Cable Range
No. Max Max Max Max Min ** Max
03* .437 (11.1) .760 (19.3) .843 (21.4) .630 (16.0) .156 (4.0) .250 (6.4)
04* .437 (11.1) .760 (19.3) .906 (23.0) .755 (19.2) .188 (4.8) .312 (7.9)
06* .500 (12.7) .760 (19.3) 1.093 (27.8) .942 (23.9) .281 (7.1) .438 (11.1)
08 .563 (14.3) .760 (19.3) 1.187 (30.1) 1.067 (27.1) .344 (8.7) .562 (14.3)
10 .563 (14.3) .760 (19.3) 1.281 (32.5) 1.192 (30.3) .375 (9.5) .625 (15.9)
12 .563 (14.3) .760 (19.3) 1.500 (38.1) 1.380 (35.1) .438 (11.1) .750 (19.1)
16 .656 (16.7) 1.073 (27.3) 1.719 (43.7) 1.535 (39.0) .562 (14.3) .938 (23.8)
20 .656 (16.7) 1.323 (33.6) 2.062 (52.4) 1.848 (46.9) .750 (19.1) 1.250 (31.8)
24 .656 (16.7) 1.323 (33.6) 2.312 (58.7) 2.255 (57.3) .781 (19.8) 1.375 (34.9)
28 1.188 (30.2) 1.572 (39.9) 2.719 (69.1) 2.505 (63.6) .969 (24.6) 1.625 (41.3)
32* 1.187 (30.1) 1.572 (39.9) 2.969 (75.4) 2.755 (70.0) 1.125 (28.6) 1.875 (47.6)
40* 1.125 (28.6) 1.572 (39.9) 3.531 (89.7) 3.255 (82.7) 1.469 (37.3) 2.375 (60.3)
* Not available in Style M clamp. ** Not Applicable Style D
