Page 230 - Circular Connector Backshells and Accessories

380-019
EMI/RFI Non-Environmental Backshell
with Strain Relief
38
Type E - Direct Coupling - Standard Profile

CONNECTOR 380 F J 019 M 24 12 D A
DESIGNATORS Product Series Strain Relief Style
A-B -C-D-E-F Connector (H, A, M, D)
*

G-H-J-K-L-S Designator Termination (Note 4)
D = 2 Rings
Angle and Profile T = 3 Rings
* Conn. Desig. B See Note 5 H = 45°
DIRECT COUPLING J = 90° Cable Entry (Tables X, XI)
See page 38-92 for straight
Shell Size (Table I)
TYPE E INDIVIDUAL Basic Part No.
AND/OR OVERALL Finish (Table II)
SHIELD TERMINATION

A Thread
J E J G
(Table I)
(Table III) (Table IV) (Table III) (Table IV)

F (Table IV)
B Typ.
(Table I)

H (Table IV)

STYLE H STYLE A STYLE M STYLE D
Heavy Duty Medium Duty Medium Duty Medium Duty
(Table X) (Table XI) (Table XI) (Table XI)
T W X .135 (3.4)
Max

Cable Cable Y Cable Cable
Range V Range Range Y Entry Z
