Page 233 - Circular Connector Backshells and Accessories

380-019
EMI/RFI Non-Environmental Backshell
with Strain Relief 38
Type E - Direct Coupling - Split Shell

TABLE III: FRONT ADAPTER TABLE IV: ELBOW DIMENSIONS
J Max - Conn. Designator Elbow E F G H
Shell A-E-F Size Max Max Max Max
Size J-H-L-S D-B-G-K C 03 .500 (12.7) 1.590 (40.4) .680 (17.3) 1.530 (38.9)
08/09 1.180 (30.0) 1.440 (36.6) 04 .500 (12.7) 1.590 (40.4) .680 (17.3) 1.530 (38.9)
10/11 1.180 (30.0) 1.440 (36.6) 06 .500 (12.7) 1.650 (41.9) .750 (19.1) 1.590 (40.4)
12/13 1.180 (30.0) 1.440 (36.6) 1.735 (44.1) 08 .560 (14.2) 1.720 (43.7) .810 (20.6) 1.660 (42.2)
14/15 1.180 (30.0) 1.440 (36.6) 1.915 (48.6) 10 .620 (15.7) 1.750 (44.5) .870 (22.1) 1.690 (42.9)
16/17 1.380 (35.0) 1.560 (39.6) 1.915 (48.6) 12 .680 (17.3) 1.850 (47.0) .930 (23.6) 1.790 (45.5)
18/19 1.380 (35.0) 1.560 (39.6) 1.915 (48.6) 16 .750 (19.1) 1.910 (48.5) 1.000 (25.4) 1.850 (47.0)
20/21 1.380 (35.0) 1.560 (39.6) 1.915 (48.6) 20 .820 (20.8) 1.970 (50.0) 1.060 (26.9) 1.910 (48.5)
22/23 1.380 (35.0) 1.560 (39.6) 1.915 (48.6) 24 .880 (22.4) 2.030 (51.6) 1.120 (28.4) 1.970 (50.0)
24/25 1.380 (35.0) 1.560 (39.6) 1.915 (48.6) 28 .940 (23.9) 2.090 (53.1) 1.180 (30.0) 2.030 (51.6)
28/29 1.610 (40.9) 1.560 (39.6) 1.915 (48.6)
32/33 1.610 (40.9) 1.750 (44.5) 1.915 (48.6) TABLE X: CABLE ENTRY
36 1.610 (40.9) 1.750 (44.5) 1.915 (48.6) Dash T V Cable Range
40 1.610 (40.9) 2.190 (55.6) 1.915 (48.6) No. Max Max Min Max
04 .780 (19.8) .957 (24.3) .125 (3.2) .312 (7.9)
TABLE V: ELBOW DIMENSIONS 06 .780 (19.8) 1.145 (29.1) .250 (6.4) .437 (11.1)
Elbow K L 08 .780 (19.8) 1.332 (33.8) .312 (7.9) .562 (14.3)
Size Max Max 10 .780 (19.8) 1.332 (33.8) .350 (8.9) .625 (15.9)
03 .340 (8.6) .681 (17.3) 12 .811 (20.6) 1.551 (39.4) .500 (12.7) .750 (19.1)
04 .270 (6.9) .731 (18.6) 16 .905 (23.0) 1.770 (45.0) .625 (15.9) .937 (23.8)
06 .270 (6.9) .731 (18.6) 20 1.092 (27.7) 2.113 (53.7) .875 (22.2) 1.250 (31.8)
08 .280 (7.1) .831 (21.1) 24 1.124 (28.5) 2.363 (60.0) 1.000 (25.4) 1.375 (34.9)
10 .420 (10.7) .981 (24.9) 28 1.399 (35.5) 2.770 (70.4) 1.250 (31.8) 1.625 (41.3)
12 .540 (13.7) 1.181 (30.0) 32 1.399 (35.5) 3.020 (76.7) 1.437 (36.5) 1.875 (47.6)

Elbow M Function C Max TABLE II: STANDARD FINISHES
Size Max Wire Bundle GLENAIR See inside back
03 1.730 (43.9) .250 (6.4) SYMBOL FINISH cover fold-out or
Cadmium Plate, Olive Drab
B
04 1.730 (43.9) .375 (9.5) M Electroless Nickel pages 13 and 14
06 1.890 (48.0) .375 (9.5) NF Cadmium Plate, Olive Drab for unabridged
08 1.890 (48.0) .500 (12.7) Over Electroless Nickel
10 1.960 (49.8) .625 (15.9) See Inside Back Cover Tables I and II.
12 1.960 (49.8) .750 (19.1) for Additional Finish Options
TABLE XI: CABLE ENTRYS
Dash W X Y Z Cable Range
No. Max Max Max Max Min ** Max
03* .437 (11.1) .760 (19.3) .843 (21.4) .630 (16.0) .156 (4.0) .250 (6.4)
04* .437 (11.1) .760 (19.3) .906 (23.0) .755 (19.2) .188 (4.8) .312 (7.9)
06* .500 (12.7) .760 (19.3) 1.093 (27.8) .942 (23.9) .281 (7.1) .438 (11.1)
08 .563 (14.3) .760 (19.3) 1.187 (30.1) 1.067 (27.1) .344 (8.7) .562 (14.3)
10 .563 (14.3) .760 (19.3) 1.281 (32.5) 1.192 (30.3) .375 (9.5) .625 (15.9)
12 .563 (14.3) .760 (19.3) 1.500 (38.1) 1.380 (35.1) .438 (11.1) .750 (19.1)
16 .656 (16.7) 1.073 (27.3) 1.719 (43.7) 1.535 (39.0) .562 (14.3) .938 (23.8)
20 .656 (16.7) 1.323 (33.6) 2.062 (52.4) 1.848 (46.9) .750 (19.1) 1.250 (31.8)
24 .656 (16.7) 1.323 (33.6) 2.312 (58.7) 2.255 (57.3) .781 (19.8) 1.375 (34.9)
28 1.188 (30.2) 1.572 (39.9) 2.719 (69.1) 2.505 (63.6) .969 (24.6) 1.625 (41.3)
32* 1.187 (30.1) 1.572 (39.9) 2.969 (75.4) 2.755 (70.0) 1.125 (28.6) 1.875 (47.6)
40* 1.125 (28.6) 1.572 (39.9) 3.531 (89.7) 3.255 (82.7) 1.469 (37.3) 2.375 (60.3)
* Not available in Style M clamp. ** Not Applicable Style D
