Page 128 - Circular Connector Backshells and Accessories
P. 128

370-005
                                                    Splash-Proof Cable Sealing Backshell
                                                                  with Strain Relief
       37
                                                          Low Profile - Rotatable Coupling



                                                            370 F S 005 M 16 10 L 6
                  CONNECTOR                 Product Series                           Length: S only (1/2 inch incre-
                DESIGNATORS                 Connector Designator                       ments: e.g. 6 = 3 inches)
               A-F-H-L-S                    Angle and Profile                        Strain Relief Style (L,G)

                  ROTATABLE                    A = 90°                               Cable Entry (Tables IV, V)
                                               B = 45°
                   COUPLING                    S = Straight                          Shell Size (Table III)

                                            Basic Part No.                           Finish (Table II)

                         Length ± .060 (1.52)
                      Min. Order Length 2.0 Inch  A Thread             Length *        .312 (7.9)
                            (See Note 6)        (Table I)           O-Rings              Max


                                                                                          * Length ± .060 (1.52)
                                                     C Typ.                                    Min. Order
                                                    (Table I)                                Length 1.5 Inch
                                                                                              (See Note 6)

                  STYLE 2
                 (STRAIGHT
                 See Note 1)                       E                                        G
                                                 (Table III)                             (Table III)
                           .88 (22.4)
                             Max                                F (Table III)



                                                                                                         H
                                                                                                     (Table III)

                  STYLE 2
                  (45° & 90°
                 See Note 1)



                                     STYLE L                                      STYLE G
                                Light Duty (Table IV)                         Light Duty (Table V)
                                     .850
                                    (21.6)                                            .072 (1.8)
                                                                                        Max
                                     Max

                                             Cable   J                                Cable  K
                                             Range                                    Range
